The cone on the left fits a 10.75 inch concrete tube and is half ogive, half conical. The The "hojo" is ogive in the center and straight conical front and back for a 6 inch tube. Then a biconic for a 8.25 in concrete tube, a 14.5 by 56 inch ogive, and then a nuclear power pod for a space station ( for those old enough to remember "donut" space stations ). The last is a 7.5 inch biconic for a scale Hermes rocket build.
Have you ever wanted to build an upscale of your favorite Estes model but there is no nose cone that shape?
Have you come across a great tube for an airframe but there is no nose cone that size?
Have you wanted to build a scale rocket or oddroc but no one makes the right nosecone?
Maybe you could make your own, but is it worth the hassle, and trial and error, of setting it all up?
NOW YOU CAN BUILD ANY OF THESE ROCKETS AND LET
PYTHON ROCKETRY MAKE THE NOSE CONE.
Custom nose cones, almost any size or shape by Python Rocketry.
I use higher density foam with over 2 1/2 times the compression resistance- 40 psi vs 15 psi,- but less than 40% increase in weight compared to standard foam. (weight can be added if needed for stability). The tips are hardwood with aluminum rod centers that extend well into the body of the cone. The tips are cut on the cone, not glued on afterward.
I cover them with 2 layers of 6 oz. fiberglass, standard. If you want heavier or high temp epoxy etc. it can be done.
I need good measurements and an accurate description or drawing of what you want.
Email to request a quote or for questions.
Standard basic construction-
red = aluminum bar
brown ring and forward = hardwood tip
airframes generally empty- hollow
outside airframes = foam
sizes and proportions vary and can be customized
After the cone is finished, I will send you a paypal invoice for the total - cone plus actual shipping
Two 16.5 x 48 ogive, ready to paint.
16 X 72 Ogive
Sample Price List
Any diameter from 5.5 to 20+
and length to 90 inches available
10.75 x 50 for high
school NASA project
7.5 x 20 scale Hermes
7.5 base, 14" max x 50
Click Nose Cone Construction below for more details
Shipping is at actual charge. Note that because of size, FedEx is well over $100 for large cones.
